Description
Product name: AB-QM DN10 (20 pcs)
Product details
| Gross weight | 0.34 kg |
| Net weight | 0.34 kg |
| EAN | 5710104089676 |
| Gross weight | 0.34 kg |
| Net weight | 0.34 kg |
| EAN | 5710104089676 |
| Actuator connection | M30 x 1.5 |
| Connection types | External Thread |
| Description | AB-QM DN 10, without test plugs, pressure independent balancing and control valve, Industry pack (20 pcs) |
| Differential pressure [kPa] [Max] | 600 kPa |
| Flow nominal [m³/h] | 0.275 m3/h |
| Media temperature [°C] [Max] | 120 °C |
| Media temperature [°C] [Min] | -10 °C |
| Pressure class | PN 16 |
| Product group | Pressure independent balancing and control valves |
| Product name | AB-QM DN10 (20 pcs) |
| Starting pressure [kPa] | 16 kPa |
| Stroke [mm] | 2.25 mm |
| Test plugs | Without test plugs |
| Type | AB-QM |
| Valve body material | DZR Brass (CW 602N) |
| Valve size | DN 10 |
| Actuator connection | M30 x 1.5 |
| Connection types | External Thread |
| Description | AB-QM DN 10, without test plugs, pressure independent balancing and control valve, Industry pack (20 pcs) |
| Differential pressure [kPa] [Max] | 600 kPa |
| Flow nominal [m³/h] | 0.275 m3/h |
| Media temperature [°C] [Max] | 120 °C |
| Media temperature [°C] [Min] | -10 °C |
| Pressure class | PN 16 |
| Product group | Pressure independent balancing and control valves |
| Product name | AB-QM DN10 (20 pcs) |
| Starting pressure [kPa] | 16 kPa |
| Stroke [mm] | 2.25 mm |
| Test plugs | Without test plugs |
| Type | AB-QM |
| Valve body material | DZR Brass (CW 602N) |
| Valve size | DN 10 |
