Description
Product name: Pressure switch, Type: KP37, Reset function: Auto, Contact function: SPDT, Regulation range [bar] Pe: 4.00 - 21.00, Regulation range [psig] Pe: 58.00 - 300.00, Pressure connection size: 1/2, Pressure connection type: G, Pressure Male/Female: Male
Product details
| Gross weight | 0.38 kg |
| Net weight | 0.35 kg |
| EAN | 5702428365369 |
| Gross weight | 0.38 kg |
| Net weight | 0.35 kg |
| EAN | 5702428365369 |
| Amb. Temp. Note | 80 °C/176 °F for max 120 min |
| Ambient temperature range [°C] [Max] | 65 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 149 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | CCC CE EAC LVD PZH RINA RMRS RoHS China c UL us UL353, CS C22.2 c UL us UL873, CS C22.2 |
| Contact function | SPDT |
| Contact rating | 120Vac,16FLA,96LRA,3APilotDuty 16 A resistive, single phase 240 V ac, 8 FLA, 48 LRA 8 A resistive, single phase 240V dc,12W pilot duty(0.05 A) |
| Differential [bar] [Max] | 3 bar |
| Differential [bar] [Min] | 1.8 bar |
| Differential [psi] [Max] | 44 psi |
| Differential [psi] [Min] | 26 psi |
| Electrical connection | Rubber cable gland |
| Electrical connection size | 6-14 mm |
| EN 60947 electrical properties | Pollution degree: 3 Rated impulse voltage: 4 kV |
| EN 60947 wiring properties | Flex, ferrules: 0.5-1.5 mm2 Flex, no ferrules: 0.7-2.5 mm2 Solid/stranded: 0.75-2.5 mm2 |
| Enclosure rating IP | IP30 |
| Enclosure rating Nema (~) | 1 |
| Max. test pressure [bar] Pe | 32 bar |
| Max. test pressure [psig] | 464 psig |
| Max. Working Pressure [bar] | 28 bar |
| Max. Working Pressure [psig] | 405 psig |
| Packing format | Multi pack |
| Pressure connection size | 1/2 |
| Pressure connection standard | ISO 228-1 |
| Pressure connection type | G |
| Pressure Male/Female | Male |
| Pressure range category | Medium pressure |
| Pressure sensing element | Bellows |
| Product accessories | Switches accessories |
| Product description | Pressure Switch |
| Product family name | KP Pressure switch |
| Product group | Switches and thermostats |
| Product name | Pressure switch |
| Quantity per packing format | 36 pc |
| Regulation range [bar] Pe [Max] | 21 bar |
| Regulation range [bar] Pe [Min] | 4 bar |
| Regulation range [psig] Pe [Max] | 300 psig |
| Regulation range [psig] Pe [Min] | 58 psig |
| Reset function | Auto |
| Serviceable | No |
| Type | KP37 |
| UL approval file name | E31024 MH27572 |
| Amb. Temp. Note | 80 °C/176 °F for max 120 min |
| Ambient temperature range [°C] [Max] | 65 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 149 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | CCC CE EAC LVD PZH RINA RMRS RoHS China c UL us UL353, CS C22.2 c UL us UL873, CS C22.2 |
| Contact function | SPDT |
| Contact rating | 120Vac,16FLA,96LRA,3APilotDuty 16 A resistive, single phase 240 V ac, 8 FLA, 48 LRA 8 A resistive, single phase 240V dc,12W pilot duty(0.05 A) |
| Differential [bar] [Max] | 3 bar |
| Differential [bar] [Min] | 1.8 bar |
| Differential [psi] [Max] | 44 psi |
| Differential [psi] [Min] | 26 psi |
| Electrical connection | Rubber cable gland |
| Electrical connection size | 6-14 mm |
| EN 60947 electrical properties | Pollution degree: 3 Rated impulse voltage: 4 kV |
| EN 60947 wiring properties | Flex, ferrules: 0.5-1.5 mm2 Flex, no ferrules: 0.7-2.5 mm2 Solid/stranded: 0.75-2.5 mm2 |
| Enclosure rating IP | IP30 |
| Enclosure rating Nema (~) | 1 |
| Max. test pressure [bar] Pe | 32 bar |
| Max. test pressure [psig] | 464 psig |
| Max. Working Pressure [bar] | 28 bar |
| Max. Working Pressure [psig] | 405 psig |
| Packing format | Multi pack |
| Pressure connection size | 1/2 |
| Pressure connection standard | ISO 228-1 |
| Pressure connection type | G |
| Pressure Male/Female | Male |
| Pressure range category | Medium pressure |
| Pressure sensing element | Bellows |
| Product accessories | Switches accessories |
| Product description | Pressure Switch |
| Product family name | KP Pressure switch |
| Product group | Switches and thermostats |
| Product name | Pressure switch |
| Quantity per packing format | 36 pc |
| Regulation range [bar] Pe [Max] | 21 bar |
| Regulation range [bar] Pe [Min] | 4 bar |
| Regulation range [psig] Pe [Max] | 300 psig |
| Regulation range [psig] Pe [Min] | 58 psig |
| Reset function | Auto |
| Serviceable | No |
| Type | KP37 |
| UL approval file name | E31024 MH27572 |
