Description
Temperature range [°C] [Min]: -50, Temperature range [°C] [Max]: 600, Insertion length [mm]: 100, Sensor element type: Pt, Sensor elem. resistance [Ohm]: 100, Electrical connection: Type B
Product details
| Gross weight | 0.11 kg |
| Net weight | 0.11 kg |
| EAN | 5702423167920 |
| Gross weight | 0.11 kg |
| Net weight | 0.11 kg |
| EAN | 5702423167920 |
| Electrical connection | Type B |
| Enclosure rating IP | IP00 |
| Extension length [in] | 1.97 in |
| Extension length [mm] | 50 mm |
| Insertion length [in] | 3.94 in |
| Insertion length [mm] | 100 mm |
| Insertion type | Fixed |
| Number of terminals [pcs] | 3 pc |
| Output signal | Ohm |
| Packing format | Multi pack |
| Product group | Sensors |
| Product name | Temperature sensor |
| Protection tube diameter [in] | 0.31 in |
| Protection tube diameter [mm] | 8 mm |
| Quantity per packing format | 20 pc |
| Sensor elem. resistance [Ohm] | 100 Ohm |
| Sensor element [pc] | 1 pc |
| Sensor element standard | EN 60751 |
| Sensor element tolerance | Class B |
| Sensor element type | Pt |
| Temperature range [°C] [Max] | 600 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 1112 °F |
| Temperature range [°F] [Min] | -58 °F |
| Type | MBT 156 |
| Type designation | MBT 156-B01-100-0-0000 |
| Wires [pcs] | 2 pc |
| Electrical connection | Type B |
| Enclosure rating IP | IP00 |
| Extension length [in] | 1.97 in |
| Extension length [mm] | 50 mm |
| Insertion length [in] | 3.94 in |
| Insertion length [mm] | 100 mm |
| Insertion type | Fixed |
| Number of terminals [pcs] | 3 pc |
| Output signal | Ohm |
| Packing format | Multi pack |
| Product group | Sensors |
| Product name | Temperature sensor |
| Protection tube diameter [in] | 0.31 in |
| Protection tube diameter [mm] | 8 mm |
| Quantity per packing format | 20 pc |
| Sensor elem. resistance [Ohm] | 100 Ohm |
| Sensor element [pc] | 1 pc |
| Sensor element standard | EN 60751 |
| Sensor element tolerance | Class B |
| Sensor element type | Pt |
| Temperature range [°C] [Max] | 600 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 1112 °F |
| Temperature range [°F] [Min] | -58 °F |
| Type | MBT 156 |
| Type designation | MBT 156-B01-100-0-0000 |
| Wires [pcs] | 2 pc |
