Description
Refrigerant: R134a, Segment usage: Refrigeration HT;Refrigeration LT;Refrigeration MT, Compressor power supply [V/Ph/Hz]: 115/1/60
Product details
| Gross weight | 7.36 kg |
| Net weight | 6.94 kg |
| EAN | 5702428916998 |
| Gross weight | 7.36 kg |
| Net weight | 6.94 kg |
| EAN | 5702428916998 |
| Application energy level | Universal |
| Applications | HBP LBP MBP |
| Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] | 4.9 Ohm |
| Base plate type | US small |
| Brand technique | Reciprocating compressor |
| Capacity control | Fixed speed |
| Colour | Black |
| Compressor power supply [V/Ph/Hz] | 115/1/60 |
| Configuration code | Single |
| Cut in current LST [A] | 16 A |
| Description | TL2.5G |
| Discharge connection angle [°] | 28 ° |
| Discharge connection comments | Rubber plug |
| Discharge connection diameter [mm] | 5 mm |
| Discharge connection material | Copper |
| Economizer | No |
| Free gas volume [cm3] | 1600 cm3 |
| Frequency [Hz] | 60 |
| Height from baseplate [mm] | 159 mm |
| High value of nominal voltage at 60Hz [V] | 115 V |
| High value of voltage range at 60Hz [V] | 127 V |
| Length [mm] | 222 mm |
| Liquid injection | No |
| Low value of nominal voltage at 60Hz [V] | 115 V |
| Low value of voltage range at 60Hz [V] | 98 V |
| LRA LST [A] | 7 A |
| Main winding resistance for single-phase compressors [Ohm] | 5.3 Ohm |
| Model number | TL2.5G |
| Motor type | RSIR |
| No. of phases (compressor) | 1 |
| Nominal cooling capacity 60 kBTU/h | 0.95 kBtu/h |
| Nominal cooling capacity at 60Hz | 0.3 kW |
| Oil quantity [cm3] | 280 cm3 |
| Oil type | POE |
| Packing format | Industrial pack |
| Packing quantity | 125 |
| Process connection angle [°] | 32 ° |
| Process connection comments | Rubber plug |
| Process connection diameter [mm] | 6.5 mm |
| Process connection material | Copper |
| Refrigerant | R134a |
| Refrigerant charge [kg] [Max] | 0.4 kg |
| Rotational speed at 60Hz [rpm] | 3600 rpm |
| Segment usage | Refrigeration LT Refrigeration MT Refrigeration HT |
| Suction connection angle [°] | 30 ° |
| Suction connection comments | Rubber plug |
| Suction connection diameter [mm] | 6.5 mm |
| Suction connection material | Copper |
| Swept volume [cm3] | 2.61 cm3 |
| Technology | Reciprocating |
| Total height [mm] | 163 mm |
| Type | TL |
| Type designation | Compressor |
| Voltage 60Hz [V] | 115 V |
| Voltage 60Hz [V] [Max] | 115 V |
| Width [mm] | 157 mm |
| Winding temperature short term [°C] [Max] | 135 °C |
| Winding temperature stat [°C] [Max] | 125 °C |
| Application energy level | Universal |
| Applications | HBP LBP MBP |
| Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] | 4.9 Ohm |
| Base plate type | US small |
| Brand technique | Reciprocating compressor |
| Capacity control | Fixed speed |
| Colour | Black |
| Compressor power supply [V/Ph/Hz] | 115/1/60 |
| Configuration code | Single |
| Cut in current LST [A] | 16 A |
| Description | TL2.5G |
| Discharge connection angle [°] | 28 ° |
| Discharge connection comments | Rubber plug |
| Discharge connection diameter [mm] | 5 mm |
| Discharge connection material | Copper |
| Economizer | No |
| Free gas volume [cm3] | 1600 cm3 |
| Frequency [Hz] | 60 |
| Height from baseplate [mm] | 159 mm |
| High value of nominal voltage at 60Hz [V] | 115 V |
| High value of voltage range at 60Hz [V] | 127 V |
| Length [mm] | 222 mm |
| Liquid injection | No |
| Low value of nominal voltage at 60Hz [V] | 115 V |
| Low value of voltage range at 60Hz [V] | 98 V |
| LRA LST [A] | 7 A |
| Main winding resistance for single-phase compressors [Ohm] | 5.3 Ohm |
| Model number | TL2.5G |
| Motor type | RSIR |
| No. of phases (compressor) | 1 |
| Nominal cooling capacity 60 kBTU/h | 0.95 kBtu/h |
| Nominal cooling capacity at 60Hz | 0.3 kW |
| Oil quantity [cm3] | 280 cm3 |
| Oil type | POE |
| Packing format | Industrial pack |
| Packing quantity | 125 |
| Process connection angle [°] | 32 ° |
| Process connection comments | Rubber plug |
| Process connection diameter [mm] | 6.5 mm |
| Process connection material | Copper |
| Refrigerant | R134a |
| Refrigerant charge [kg] [Max] | 0.4 kg |
| Rotational speed at 60Hz [rpm] | 3600 rpm |
| Segment usage | Refrigeration LT Refrigeration MT Refrigeration HT |
| Suction connection angle [°] | 30 ° |
| Suction connection comments | Rubber plug |
| Suction connection diameter [mm] | 6.5 mm |
| Suction connection material | Copper |
| Swept volume [cm3] | 2.61 cm3 |
| Technology | Reciprocating |
| Total height [mm] | 163 mm |
| Type | TL |
| Type designation | Compressor |
| Voltage 60Hz [V] | 115 V |
| Voltage 60Hz [V] [Max] | 115 V |
| Width [mm] | 157 mm |
| Winding temperature short term [°C] [Max] | 135 °C |
| Winding temperature stat [°C] [Max] | 125 °C |
