Description
CJ2MCPU31 OMRON CPU 5K STEP/64K DATA E-NET PORT
CJ2MCPU31
CJ2M-CPU31
| Brand: | Omron |
| Family: | Sysmac |
| Series: | CJ2M |
| Product Type: | Modular PLC CPU |
| Manufacturer Part No.: | CJ2M-CPU31 |
| Supply Voltage AC 50 Hz: | 85V - 264V |
| Supply Voltage AC 60 Hz: | 85V - 264V |
| Supply Voltage DC: | 24V |
| Voltage Type: | AC/DC |
| Max. No. of Time Switches: | 4090 |
| Max. No. of Addressable Analogue I/O Points: | 2048 |
| Max. No.of Addressable Digital I/O Points: | 4096 |
| Format: | Modular |
| Processing Time (1K, Binary Operations): | 0.04ms |
| No. of Ethernet Ports: | 1 |
| No. of USB Ports: | 1 |
| No. of Other Interfaces: | 1 |
| Supports Protocol for TCP/IP: | Yes |
| Supports Protocol for EtherNet/IP: | Yes |
| Type of Memory: | FLASH |
| Memory Size: | 1164kByte |
| Rail Mounting Possible: | Yes |
| Category according to EN 954-1: | B |
| Performance Level acc. to EN ISO 13849-1: | Level a |
| Width: | 62mm |
| Height: | 90mm |
| Depth: | 84.5mm |
| GTIN: | 04548583498433 |
