Description
Frequency converter
FC-103P75KT4E55H5XGCXXXSXXXXA0BPCXRXXDX
VLT® Refrigeration Drive FC-103
75 KW / 100 HP,
Three phase, 380 - 480 VAC,IP55 / Type 12
Maritime use excl. EMC.
No brake chopper
Graphical Loc. Cont. Panel
Coated PCB, No Mains Option
Latest release std. SW.
PROFIBUS DP MCA 101, MCB-105 Relay Card
MCB-113 Ext. Relay Card, No D option
Frame: C2
Other options according to Model code
Model code:
FC-103P75KT4E55H5XGCXXXSXXXXA0BPCXRXXDX
Whether you want to operate compressors, pumps or fans, the VLT®Refrigeration Drive FC 103 gives you the opportunity to save energy andextend the lifetime of the components.
| Gross weight | 65.3 Kilogram | ||
| Net weight | 65 Kilogram | ||
| EAN | 5714853164929 |
| Product View (Switch) | GLBL | Global (Standard) | |
| Product Group | FC- | VLT® Refrigeration Drive | |
| Series | 103 | 103 | |
| Power Rating | P75K | 75 KW / 100 HP | |
| Phase | T | Three phase | |
| Mains Voltage | 4 | 380 - 480 VAC | |
| Enclosure | E55 | IP55 / Type 12 | |
| RFI Filter | H5 | Maritime use excl. EMC. | |
| Brake - Safe Stop | X | No brake chopper | |
| LCP | G | Graphical Loc. Cont. Panel | |
| Coating PCB | C | Coated PCB | |
| Mains Option | X | No Mains Option | |
| Adaptation A | X | Standard Cable Entries | |
| Adaptation B | X | No adaptation | |
| Software Release | SXXX | Latest release std. SW. | |
| Software Language Pack | X | Standard Language Pack | |
| A Option | A0 | PROFIBUS DP MCA 101 | |
| B Option | BP | MCB-105 Relay Card | |
| C0 Option MCO | CX | No C0 option | |
| C1 Option | R | MCB-113 Ext. Relay Card | |
| C Option Software | XX | No software option | |
| D Option | DX | No D option | |
| Frame Size | C2 | C2 | |
| Product Catalog | NO_VIEW | NO VIEW | |
| Typecode Part 2 | XXXSXXXXA0BPCXRXXDX | ||
| Power 110% (NO) [KW] | 75 | 75 | |
| Height [mm] | 780,0 | 780,0 | |
| Width w/ no C options [mm] | 370,0 | 370,0 | |
| Depth [mm] | 332,0 | 332,0 | |
| Depth with Option A/B [mm] | 332,0 | 332,0 | |
| kVA | 102 | 102 | |
| Power Loss NO [W] | 1384 | 1384 | |
| Power Loss NO [W] | 1384 | 1384 | |
| Continuous Current (NO) [A] | 147 | 147 | |
| Intermittent Current (NO) [A] | 162 | 162 | |
| Continuous Current (NO) [A] | 130 | 130 | |
| Intermittent Current (NO) [A] | 143 | 143 | |
| Calculated Gross Weight [kg] | 61.3 | ||
| Calculated Net Weight [kg] | 61 | ||
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a | |
| Recommended Plant | ERR01 | ERR01 | |
| Vendor | ERR01 | Cannot Determine Vendor | |
| Recommended Factory | ERR01 | Cannot Determine Vendor | |
| Modelcode01 | FC-103P75KT4E55H5XGC | ||
| Modelcode02 | XXXSXXXXA0BPCXRXXDX |
