Description
Product name: Solenoid coil, Type: BJ120CS, Supply voltage [V] AC: 110, Enclosure rating IP: IP30, Coil connection: Junction box, Actuator size: 13.5 mm
Product details
| Gross weight | 0.41 kg |
| Net weight | 0.39 kg |
| EAN | 5702428841146 |
| Gross weight | 0.41 kg |
| Net weight | 0.39 kg |
| EAN | 5702428841146 |
| Actuator size | 13.5 mm |
| Ambient temperature range [°C] [Max] | 50 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 120 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | C UL US LISTED LLC CDC TYSK |
| Cable length [in] | 8 in |
| Cable length [m] | 0.2 m |
| Coil connection | Junction box |
| Coil design standard | UL 429 |
| Coil fastening | Clip-on |
| Coil winding insulation class | Class H to IEC 85 |
| Colour | Black |
| Compliance | UL 429 |
| Electrical conn. comments | Flying leads |
| Electrical connection | Junction Box |
| Electrical connection standard | UL50E CLASS 2 |
| Enclosure rating IP | IP30 |
| Enclosure rating Nema (~) | 2 |
| Frame design | Ext. metal frame |
| Frequency [Hz] | 50/60 Hz |
| Packing format | Multi pack |
| Parts Program name | EV210B EV215B EV220B 15 - 50 EV220B 6 - 22 EV225B EV245B EV250B |
| Pollution degree | 3 |
| Power consumption 50Hz [VA] | 29 VA |
| Power consumption 60Hz [VA] | 29 VA |
| Power consumption [W] 50Hz | 16 W |
| Power consumption [W] 60Hz | 15 W |
| Product accessories | Solenoid coil accessories |
| Product group | Solenoid valves |
| Product name | Solenoid coil |
| Quantity per packing format | 35 pc |
| Rel. Humidity [% RH] [Max] | 97 % |
| Rel. Humidity [% RH] [Min] | 0 % |
| Rel. Humidity conditions | Non-condensation |
| Serviceable | No |
| Spare part number | 018F4110 |
| Supply voltage 50Hz Max [V] | 110 V |
| Supply voltage 60Hz Max [V] | 120 V |
| Supply voltage 60Hz Min [V] | 110 V |
| Supply voltage [V] AC | 110 V |
| Type | BJ120CS |
| Type designation | BJ120CS |
| UL approval file name | MH29671 |
| Actuator size | 13.5 mm |
| Ambient temperature range [°C] [Max] | 50 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 120 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | C UL US LISTED LLC CDC TYSK |
| Cable length [in] | 8 in |
| Cable length [m] | 0.2 m |
| Coil connection | Junction box |
| Coil design standard | UL 429 |
| Coil fastening | Clip-on |
| Coil winding insulation class | Class H to IEC 85 |
| Colour | Black |
| Compliance | UL 429 |
| Electrical conn. comments | Flying leads |
| Electrical connection | Junction Box |
| Electrical connection standard | UL50E CLASS 2 |
| Enclosure rating IP | IP30 |
| Enclosure rating Nema (~) | 2 |
| Frame design | Ext. metal frame |
| Frequency [Hz] | 50/60 Hz |
| Packing format | Multi pack |
| Parts Program name | EV210B EV215B EV220B 15 - 50 EV220B 6 - 22 EV225B EV245B EV250B |
| Pollution degree | 3 |
| Power consumption 50Hz [VA] | 29 VA |
| Power consumption 60Hz [VA] | 29 VA |
| Power consumption [W] 50Hz | 16 W |
| Power consumption [W] 60Hz | 15 W |
| Product accessories | Solenoid coil accessories |
| Product group | Solenoid valves |
| Product name | Solenoid coil |
| Quantity per packing format | 35 pc |
| Rel. Humidity [% RH] [Max] | 97 % |
| Rel. Humidity [% RH] [Min] | 0 % |
| Rel. Humidity conditions | Non-condensation |
| Serviceable | No |
| Spare part number | 018F4110 |
| Supply voltage 50Hz Max [V] | 110 V |
| Supply voltage 60Hz Max [V] | 120 V |
| Supply voltage 60Hz Min [V] | 110 V |
| Supply voltage [V] AC | 110 V |
| Type | BJ120CS |
| Type designation | BJ120CS |
| UL approval file name | MH29671 |
