Description
Product name: Solenoid coil, Type: BH230CS, Supply voltage [V] AC: 230, Enclosure rating IP: IP67, Coil connection: Junction Box with rectifier, Actuator size: 13.5 mm
Product details
| Gross weight | 0.68 kg |
| Net weight | 0.64 kg |
| EAN | 5702423182435 |
| Gross weight | 0.68 kg |
| Net weight | 0.64 kg |
| EAN | 5702423182435 |
| Actuator size | 13.5 mm |
| Ambient temperature range [°C] [Max] | 50 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 120 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | LLC CDC TYSK |
| Coil connection | Junction Box with rectifier |
| Coil fastening | Clip-on |
| Colour | Blue |
| Electrical conn. comments | With rectifier |
| Electrical connection | Terminal box |
| Electrical connection size | Pg 13.5 |
| Electrical connector | Screwed cable entry |
| Enclosure rating IP | IP67 |
| Frequency [Hz] | 50/60 Hz |
| Packing format | Multi pack |
| Parts Program name | EV210B EV212B EV220B 15 - 50 EV220B 6 - 22 EV220B 65 - 100 EV250B EV251B |
| Power consumption 50Hz [VA] | 24 VA |
| Power consumption 60Hz [VA] | 24 VA |
| Power consumption [W] 50Hz | 22 W |
| Power consumption [W] 60Hz | 22 W |
| Product accessories | Solenoid coil accessories |
| Product group | Solenoid valves |
| Product name | Solenoid coil |
| Quantity per packing format | 12 pc |
| Rel. Humidity [% RH] [Max] | 100 % |
| Rel. Humidity [% RH] [Min] | 0 % |
| Serviceable | No |
| Spare part number | 018F7301 |
| Supply voltage 50Hz Max [V] | 230 V |
| Supply voltage 60Hz Max [V] | 230 V |
| Supply voltage [V] a.c. | 230 V |
| Supply voltage [V] AC | 230 V |
| Type | BH230CS |
| Type designation | BH230CS |
| Actuator size | 13.5 mm |
| Ambient temperature range [°C] [Max] | 50 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 120 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | LLC CDC TYSK |
| Coil connection | Junction Box with rectifier |
| Coil fastening | Clip-on |
| Colour | Blue |
| Electrical conn. comments | With rectifier |
| Electrical connection | Terminal box |
| Electrical connection size | Pg 13.5 |
| Electrical connector | Screwed cable entry |
| Enclosure rating IP | IP67 |
| Frequency [Hz] | 50/60 Hz |
| Packing format | Multi pack |
| Parts Program name | EV210B EV212B EV220B 15 - 50 EV220B 6 - 22 EV220B 65 - 100 EV250B EV251B |
| Power consumption 50Hz [VA] | 24 VA |
| Power consumption 60Hz [VA] | 24 VA |
| Power consumption [W] 50Hz | 22 W |
| Power consumption [W] 60Hz | 22 W |
| Product accessories | Solenoid coil accessories |
| Product group | Solenoid valves |
| Product name | Solenoid coil |
| Quantity per packing format | 12 pc |
| Rel. Humidity [% RH] [Max] | 100 % |
| Rel. Humidity [% RH] [Min] | 0 % |
| Serviceable | No |
| Spare part number | 018F7301 |
| Supply voltage 50Hz Max [V] | 230 V |
| Supply voltage 60Hz Max [V] | 230 V |
| Supply voltage [V] a.c. | 230 V |
| Supply voltage [V] AC | 230 V |
| Type | BH230CS |
| Type designation | BH230CS |
