Description
Product name: Electric regulating valve, Type: CCM 20, Refrigerants: R134a;R744, Further information: Solder, ODF
Product details
| Gross weight | 2.19 kg |
| Net weight | 2.06 kg |
| EAN | 5702428375726 |
| Gross weight | 2.19 kg |
| Net weight | 2.06 kg |
| EAN | 5702428375726 |
| Ambient temperature range [°C] [Max] | 60 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 140 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | C UR US EAC LLC CDC TYSK |
| Connection Solder size [in] | 7/8 in |
| Connection standard | EN10220 |
| Connection Weld size [in] | 3/4 in |
| Cv value [gal/min] | 1.856 gal/min |
| Diff.press.setting range [bar] | 50 bar |
| Diff.press.setting range [psi] | 725 psi |
| Enclosure rating IP | IP67 |
| Further information | Solder, ODF |
| Kv value [m³/h] | 1.85 m3/h |
| Max. Working Pressure [bar] | 90 bar |
| Max. Working Pressure [psig] | 1305 psig |
| MaxOPD [bar] | 50 bar |
| MaxOPD [psig] | 725 psig |
| Packing format | Single pack |
| Product description | Electric Expansion Valve |
| Product family name | CCM |
| Product group | Press. and temp. regul. valves |
| Product name | Electric regulating valve |
| Quantity per packing format | 1 pc |
| Refrigerants | R134a R744 |
| Temperature range [°C] [Max] | 60 °C |
| Temperature range [°C] [Min] | -40 °C |
| Temperature range [°F] [Max] | 140 °F |
| Temperature range [°F] [Min] | -40 °F |
| Type | CCM 20 |
| Ambient temperature range [°C] [Max] | 60 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 140 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | C UR US EAC LLC CDC TYSK |
| Connection Solder size [in] | 7/8 in |
| Connection standard | EN10220 |
| Connection Weld size [in] | 3/4 in |
| Cv value [gal/min] | 1.856 gal/min |
| Diff.press.setting range [bar] | 50 bar |
| Diff.press.setting range [psi] | 725 psi |
| Enclosure rating IP | IP67 |
| Further information | Solder, ODF |
| Kv value [m³/h] | 1.85 m3/h |
| Max. Working Pressure [bar] | 90 bar |
| Max. Working Pressure [psig] | 1305 psig |
| MaxOPD [bar] | 50 bar |
| MaxOPD [psig] | 725 psig |
| Packing format | Single pack |
| Product description | Electric Expansion Valve |
| Product family name | CCM |
| Product group | Press. and temp. regul. valves |
| Product name | Electric regulating valve |
| Quantity per packing format | 1 pc |
| Refrigerants | R134a R744 |
| Temperature range [°C] [Max] | 60 °C |
| Temperature range [°C] [Min] | -40 °C |
| Temperature range [°F] [Max] | 140 °F |
| Temperature range [°F] [Min] | -40 °F |
| Type | CCM 20 |
