Description
Product details
| Gross weight | 0.07 kg |
| Net weight | 0.06 kg |
| EAN | 5702428275040 |
| Gross weight | 0.07 kg |
| Net weight | 0.06 kg |
| EAN | 5702428275040 |
| + output | Pin 2 |
| + supply | Pin 1 |
| - common | Pin 3 |
| Accuracy, max. +/- FS [%] | 2 % |
| Ambient temperature range [°C] [Max] | 100 °C |
| Ambient temperature range [°C] [Min] | -30 °C |
| Electrical conn. Male/Female | Female |
| Electrical connection | Molex |
| Enclosure rating IP | IP66 |
| Medium temperature range [°C] [Max] | 120 °C |
| Medium temperature range [°C] [Min] | -30 °C |
| Output signal [V] [Max] | 4.5 V |
| Output signal [V] [Min] | 0.5 V |
| Overload pressure max. [bar] | 38.5 bar |
| Packing format | Industrial pack |
| Pressure connection HEX [mm] | 14 mm |
| Pressure connection notes | With Schrader Depressor |
| Pressure connection size | 7/16-20 |
| Pressure connection standard | ASME B1.1 |
| Pressure connection type | UNF |
| Pressure Male/Female | Female |
| Pressure range [bar] [Max] | 30 bar |
| Pressure range [bar] [Min] | 0 bar |
| Pressure unit reference | Gauge (relative) |
| Product family name | NSK |
| Product group | Sensors |
| Product name | Pressure transmitter |
| Quantity per packing format | 20 pc |
| Refrigerants | R134a R404A R407C R410A |
| Specification key | NSK-BC030I-U068 |
| Supply voltage [V] DC | 5 V |
| Type | NSK |
| + output | Pin 2 |
| + supply | Pin 1 |
| - common | Pin 3 |
| Accuracy, max. +/- FS [%] | 2 % |
| Ambient temperature range [°C] [Max] | 100 °C |
| Ambient temperature range [°C] [Min] | -30 °C |
| Electrical conn. Male/Female | Female |
| Electrical connection | Molex |
| Enclosure rating IP | IP66 |
| Medium temperature range [°C] [Max] | 120 °C |
| Medium temperature range [°C] [Min] | -30 °C |
| Output signal [V] [Max] | 4.5 V |
| Output signal [V] [Min] | 0.5 V |
| Overload pressure max. [bar] | 38.5 bar |
| Packing format | Industrial pack |
| Pressure connection HEX [mm] | 14 mm |
| Pressure connection notes | With Schrader Depressor |
| Pressure connection size | 7/16-20 |
| Pressure connection standard | ASME B1.1 |
| Pressure connection type | UNF |
| Pressure Male/Female | Female |
| Pressure range [bar] [Max] | 30 bar |
| Pressure range [bar] [Min] | 0 bar |
| Pressure unit reference | Gauge (relative) |
| Product family name | NSK |
| Product group | Sensors |
| Product name | Pressure transmitter |
| Quantity per packing format | 20 pc |
| Refrigerants | R134a R404A R407C R410A |
| Specification key | NSK-BC030I-U068 |
| Supply voltage [V] DC | 5 V |
| Type | NSK |
