Description
Pressure connection type: UNF, Pressure connection size: 7/16-20, Electrical connection: Molex
Product details
| Gross weight | 0.07 kg |
| Net weight | 0.09 kg |
| EAN | 5702428275002 |
| Gross weight | 0.07 kg |
| Net weight | 0.09 kg |
| EAN | 5702428275002 |
| + supply | Pin 1 |
| - common | Pin 3 |
| Accuracy, max. +/- FS [%] | 3 % |
| Ambient temperature range [°C] [Max] | 70 °C |
| Ambient temperature range [°C] [Min] | -20 °C |
| Electrical conn. Male/Female | Female |
| Electrical connection | Molex |
| Enclosure rating IP | IP66 |
| Identical product | 061H5080 |
| Medium temperature range [°C] [Max] | 70 °C |
| Medium temperature range [°C] [Min] | -20 °C |
| Output signal [mA] [Max] | 20 mA |
| Output signal [mA] [Min] | 4 mA |
| Overload pressure max. [bar] | 38.5 bar |
| Packing format | Industrial pack |
| Pressure connection HEX [mm] | 14 mm |
| Pressure connection notes | With Schrader Depressor |
| Pressure connection size | 7/16-20 |
| Pressure connection standard | ASME B1.1 |
| Pressure connection type | UNF |
| Pressure Male/Female | Female |
| Pressure range [bar] [Max] | 10 bar |
| Pressure range [bar] [Min] | -0.5 bar |
| Pressure unit reference | Gauge (relative) |
| Product family name | XSK |
| Product group | Sensors |
| Product name | Pressure transmitter |
| Quantity per packing format | 20 pc |
| Refrigerants | R134a R404A R407C R410A |
| Specification key | XSK-AC10I-U188 |
| Supply voltage [V] DC [Max] | 28 V |
| Supply voltage [V] DC [Min] | 10.5 V |
| Type | XSK |
| + supply | Pin 1 |
| - common | Pin 3 |
| Accuracy, max. +/- FS [%] | 3 % |
| Ambient temperature range [°C] [Max] | 70 °C |
| Ambient temperature range [°C] [Min] | -20 °C |
| Electrical conn. Male/Female | Female |
| Electrical connection | Molex |
| Enclosure rating IP | IP66 |
| Identical product | 061H5080 |
| Medium temperature range [°C] [Max] | 70 °C |
| Medium temperature range [°C] [Min] | -20 °C |
| Output signal [mA] [Max] | 20 mA |
| Output signal [mA] [Min] | 4 mA |
| Overload pressure max. [bar] | 38.5 bar |
| Packing format | Industrial pack |
| Pressure connection HEX [mm] | 14 mm |
| Pressure connection notes | With Schrader Depressor |
| Pressure connection size | 7/16-20 |
| Pressure connection standard | ASME B1.1 |
| Pressure connection type | UNF |
| Pressure Male/Female | Female |
| Pressure range [bar] [Max] | 10 bar |
| Pressure range [bar] [Min] | -0.5 bar |
| Pressure unit reference | Gauge (relative) |
| Product family name | XSK |
| Product group | Sensors |
| Product name | Pressure transmitter |
| Quantity per packing format | 20 pc |
| Refrigerants | R134a R404A R407C R410A |
| Specification key | XSK-AC10I-U188 |
| Supply voltage [V] DC [Max] | 28 V |
| Supply voltage [V] DC [Min] | 10.5 V |
| Type | XSK |
