Description
Process Connections: G1/4 , ISO 228-1-A, Temperature range [°C] [Min]: -50, Temperature range [°C] [Max]: 150, Insertion length [mm]: 28, Sensor element type: Pt, Sensor elem. resistance [Ohm]: 1000, Protection tube material: Brass, Electrical connection: AMP Junior Power Timer, Electrical connection size: 2 pin
Product details
| Gross weight | 0.03 kg |
| Net weight | 0.26 kg |
| EAN | 5702423286409 |
| Gross weight | 0.03 kg |
| Net weight | 0.26 kg |
| EAN | 5702423286409 |
| Ambient temperature max. [°C] | 125 °C |
| Ambient temperature max. [°F] | 257 °F |
| Connection material | Brass |
| Connection type | G |
| Electrical connection | AMP Junior Power Timer |
| Electrical connection size | 2 pin |
| Enclosure rating IP | IP67 |
| Insertion length [in] | 1.1 in |
| Insertion length [mm] | 28 mm |
| Insertion type | Fixed |
| Output signal | Ohm |
| Packing format | Multi pack |
| Process connection Male/Female | Male |
| Process connection material | Brass |
| Process Connections | G1/4 , ISO 228-1-A |
| Product Group | 2/2 DIRECTIONAL VALVE |
| Product group | Sensors |
| Product name | Temperature sensor |
| Protection tube diameter [in] | 0.17 in |
| Protection tube diameter [mm] | 4.2 mm |
| Protection tube material | Brass |
| Quantity per packing format | 40 pc |
| Sensor elem. resistance [Ohm] | 1000 Ohm |
| Sensor element [pc] | 1 pc |
| Sensor element standard | EN 60751 |
| Sensor element tolerance | Class B |
| Sensor element type | Pt |
| Sensor Insert | Fixed |
| Temperature range [°C] [Max] | 150 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 302 °F |
| Temperature range [°F] [Min] | -58 °F |
| Type | MBT 3270 |
| Type designation | MBT 3270-02000-028-00300-000 |
| Wires [pcs] | 2 pc |
| Ambient temperature max. [°C] | 125 °C |
| Ambient temperature max. [°F] | 257 °F |
| Connection material | Brass |
| Connection type | G |
| Electrical connection | AMP Junior Power Timer |
| Electrical connection size | 2 pin |
| Enclosure rating IP | IP67 |
| Insertion length [in] | 1.1 in |
| Insertion length [mm] | 28 mm |
| Insertion type | Fixed |
| Output signal | Ohm |
| Packing format | Multi pack |
| Process connection Male/Female | Male |
| Process connection material | Brass |
| Process Connections | G1/4 , ISO 228-1-A |
| Product Group | 2/2 DIRECTIONAL VALVE |
| Product group | Sensors |
| Product name | Temperature sensor |
| Protection tube diameter [in] | 0.17 in |
| Protection tube diameter [mm] | 4.2 mm |
| Protection tube material | Brass |
| Quantity per packing format | 40 pc |
| Sensor elem. resistance [Ohm] | 1000 Ohm |
| Sensor element [pc] | 1 pc |
| Sensor element standard | EN 60751 |
| Sensor element tolerance | Class B |
| Sensor element type | Pt |
| Sensor Insert | Fixed |
| Temperature range [°C] [Max] | 150 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 302 °F |
| Temperature range [°F] [Min] | -58 °F |
| Type | MBT 3270 |
| Type designation | MBT 3270-02000-028-00300-000 |
| Wires [pcs] | 2 pc |
