Description
VLT® Decentral Drive FCD 302 1.5 kW / 2.0 HP, 380-480VAC (Three phased), Std. Black IP66/NEMA4X, RFI Class A1/C2, No brake, Compl. small stand alone, No brackets, Metric threads, No switch option, With display connector FCD302P1K5T4B66H1X1XMXCXXXXXAXBXXXXXXDX More details
The VLT® Decentral Drive FCD 302 is a complete frequency converter designed for decentral mounting. It can be mounted on the machine/wall - close to the motor - or directly on the motor. The decentral design reduces the need for central control panels and space-consuming motor control cabinets are eliminated. In addition, the need for long screened motor cables is significantly reduced. Product Data: 1.5 kW / 2.0 HP, 380-480VAC (Three phased), Std. Black IP66/NEMA4X
The VLT® Decentral Drive FCD 302 is a complete frequency converter designed for decentral mounting. It can be mounted on the machine/wall - close to the motor - or directly on the motor. The decentral design reduces the need for central control panels and space-consuming motor control cabinets are eliminated. In addition, the need for long screened motor cables is significantly reduced. Product Data: 1.5 kW / 2.0 HP, 380-480VAC (Three phased), Std. Black IP66/NEMA4X
| CHARACTERISTIC | VALUE |
|---|---|
| PRODUCT GROUP | (FCD) Decentral Drive |
| VLT SERIES | (302) 302 Series |
| POWER RATING | (P1K5) 1.5 kW / 2.0 HP |
| MAINS VOLTAGE | (T4) 380-480VAC (Three phased) |
| ENCLOSURE | (B66) Std. Black IP66/NEMA4X |
| RFI FILTER | (H1) RFI Class A1/C2 |
| BRAKE | (X) No brake |
| HARDWARE CONFIGURATION | (1) Compl. small stand alone |
| BRACKETS | (X) No brackets |
| THREADS | (M) Metric threads |
| SWITCH OPTION | (X) No switch option |
| DISPLAY | (C) With display connector |
| SENSOR PLUGS | (X) No sensor plugs |
| MOTOR PLUG | (X) No motor plug |
| MAINS PLUG | (X) No mains plug |
| FIELDBUS PLUG | (X) No fieldbus plug |
| RESERVED | (X) Reserved |
| A OPTION | (AX) No fieldbus option |
| B OPTION | (BX) No B option |
| RESERVED FOR SW | (XXXXX) Reserved for SW |
| D OPTION | (DX) No option |
| TYPECODE | FCD302P1K5T4B66H1X1XMXCXXXXX |
| TYPECODE PART 2 | AXBXXXXXXDX |
| PRODUCT CATALOG | Global (Standard) |
| VENDOR REGION | Northern Europe |
| VENDOR | Factory DK |
