Description
VLT® OneGearDrive Standard, 1.5 - 3.0 KW, 14.13, 30 mm, Mild steel, Without CSA/UL, Horiz., conn. up or down, Without brake, Terminal Box More details
| CHARACTERISTIC | VALUE |
|---|---|
| PRODUCT VIEW (SWITCH) | Global (Standard) |
| PRODUCT GROUP | (OGD) VLT® OneGearDrive |
| PRODUCT VARIANT | (S) Standard |
| GEAR TYPE | (K) Bevel Gear |
| SIZE | (2) 400 Nm |
| GEAR RATIO | (14K13) 14.13 |
| OUTPUT SHAFT DESIGN | (1) Hollow shaft |
| OUTPUT SHAFT SIZE | (30) 30 mm |
| OUTPUT SHAFT MATERIAL | (1) Mild steel |
| MOTOR SIZE | (L09) 1.5 - 3.0 KW |
| RESOLVER | (RX) Without Resolver |
| MOTOR CONNECTION | (TB) Terminal Box |
| CONNECTOR POSITION | (1) Top |
| INSTALLATION POSITION | (P2) Horiz., conn. up or down |
| SURFACE COATING | (S) Standard |
| RAL COLOR CODE | (9010) Standard white |
| LUBRICANTS | (H1) Food grade oil |
| BRAKE | (BXXX) Without brake |
| CSA / UL | (X) Without CSA/UL |
| RESERVED A | (X) Reserved A |
| RESERVED B | (X) Reserved B |
| RESERVED C | (X) Reserved C |
| TYPECODE | OGDSK214K131301L09RXTB1P2 |
| TYPECODE PART 2 | S9010H1BXXXXXXX |
| PRODUCT CATALOG | NO VIEW |
| ORIGINAL PRODUCT MATRIX | (STD) Standard Drive |
| VENDOR REGION | Cannot Determine Region |
| VENDOR | Cannot Determine Vendor |
| CALCULATED NET WEIGHT | 28,500 |
| CALCULATED GROSS WEIGHT | 29,500 |
