Description
VLT Automation Drive FC-302 5.5 KW / 7.5 HP, 380-500 VAC, IP20 / Chassis,RFI Class A1/B (C1), Brake chopper FC-302P5K5T5E20H1BXCXXXSXXXXAUBXCXXXXD0
Product details
| Gross weight | 6.9 kg |
| Net weight | 6.6 kg |
| Volume | 22.04 l |
| EAN | 5710108175658 |
VLT AUTOMATIONDRIVE FC 300 SERIES
| Product Group | FC- | VLT AutomationDrive FC- |
| Series | 302 | 302 |
| Power Rating | P5K5 | (P5K5) 5.5 KW / 7.5 HP |
| Phase | T | Three phase |
| Mains Voltage | 5 | 380 - 500 VAC |
| Enclosure | E20 | (E20) IP20 / Chassis |
| RFI Filter | H1 | (H1) RFI Class A1/B (C1) |
| Brake - Safe Stop | B | Brake chopper |
| LCP | X | No Loc. Cont. Panel |
| Coating PCB | C | Coated PCB |
| Mains Option | X | No Mains Option |
| Adaptation A | X | Standard Cable Entries |
| Adaptation B | X | No adaptation |
| A Option | AU | PROFIBUS Converter MCA114 |
| B Option | BX | No B Option |
| C0 Option MCO | CX | No C0 option |
| C1 Option | X | No C1 option |
| C Option Software | XX | No software option |
| D Option | D0 | MCB-107 24V DC backup |
| Frame Size | A3 | A3 |
| Typecode Part 1 | FC-302P5K5T5E20H1BXC | |
| Typecode Part 2 | XXXSXXXXAUBXCXXXXD0 | |
| Calculated Gross Weight | 7.1 | |
| Calculated Net Weight [kg] | 6.8 | |
| Continuous Current (HO) [A] | 13 | |
| Continuous Current (HO) [A] | 11 | |
| Continuous Current (NO) [A] | NV | |
| Continuous Current (NO) [A] | NV | |
| Depth [mm] | 205,0 | |
| Depth with Option A/B [mm] | 220,0 | |
| Height [mm] | 268,0 | |
| Height w/ Regen/Loadshare [mm] | NV | |
| Intermittent Current (HO) [A] | 20.8 | |
| Intermittent Current (HO) [A] | 17.6 | |
| Intermittent Current (NO) [A] | NV | |
| Intermittent Current (NO) [A] | NV | |
| kVA | 9.01 | |
| Material Gross Weight | 6.9 | |
| Material Net Weight | 6.6 | |
| Modelcode01 | FC-302P5K5T5E20H1BXC | |
| Modelcode02 | XXXSXXXXAUBXCXXXXD0 | |
| Power 110% (NO) [KW] | NV | |
| Power 150% (HO) [KW] | NV | |
| Power 160% (HO) [KW] | 5.5 | |
| Power 180% (HO) [KW] | NV | |
| Power Loss HO [W] | 187 | |
| Power Loss HO [W] | 187 | |
| Power Loss NO [W] | NV | |
| Power Loss NO [W] | NV | |
| Product Catalog | NO_VIEW | NO VIEW |
| Product View (Switch) | GLBL | Global (Standard) |
| Software Language Pack | X | Standard Language Pack |
| Software Release | SXXX | Latest release std. SW. |
| Vendor | ERR01 | Cannot Determine Vendor |
| Width w/ no C options [mm] | 130,0 |
