Description
VLT® Decentral FCD 300 More details
| CHARACTERISTIC | VALUE |
|---|---|
| PRODUCT VIEW (SWITCH) | Global (Standard) |
| PRODUCT GROUP | (FCD) Decentral Freq Convert |
| VLT SERIES | (3) VLT® FCD / DMS Series |
| POWER RATING | (03) 0.37kW / 0.5 HP |
| DEDICATED APPLICATION | (P) Process |
| PHASE | (T) Three Phases |
| MAINS VOLTAGE U(IN) | (4) 380-480V +/- 10% 50/60Hz |
| ENCLOSURE TYPE | (P) Top-coated compact |
| ENCLOSURE CLASS | (66) IP66 |
| HARDWARE CONFIGURATION | (EX) Ext. without brake |
| RFI FILTER | (R1) EN 55011 Class A1 |
| DISPLAY | (DC) With display connector |
| FIELDBUS OPTION | (F10) Profibus DP |
| TERMINAL CONNECTION | (T62) Wall, metr, dbl, switch |
| COATING | (C0) Without coating |
| FRAME SIZE | A-Frame |
| TYPECODE | FCD303PT4P66EXR1DCF10T62C0 |
| PRODUCT CATALOG | NO VIEW |
| ORIGINAL PRODUCT MATRIX | (STD) Standard Drive |
| VENDOR REGION | Cannot Determine Region |
| VENDOR | Cannot Determine Vendor |
