180L1035 Danfoss Valve, VDHT 1 ED NO

Write a Review
SKU:
180L1035
Availability:
2 - 3 weeks
688.51€

Product details Gross weight 2.38 kg Net weight 2.22 kg Gross weight 2.38 kg Net weight 2.22 kg   Actua…

Adding to cart… The item has been added
Ask for a Quotation

Ask for a Quotation

Feel free to inquire
Request a Quote
  • Security Image 1
Description

Product details

Gross weight 2.38 kg
Net weight 2.22 kg
Gross weight 2.38 kg
Net weight 2.22 kg



Actuator size [mm] 13.5 mm
Body material AISI 304
Closing Time [ms] [Max] 2000 ms
Closing Time [ms] [Min] 1200 ms
Connection standard NPT
Connection type Thread
Flow [gpm] [Max] 40 gal/min
Flow [gpm] [Min] 0 gal/min
Flow [l/min] [Max] 150 L/min
Flow [l/min] [Min] 0 L/min
Function NO
Inlet connection size [in] 1 in
Material type Neutral media
Media temperature [°C] [Max] 90 °C
Media temperature [°C] [Min] 2 °C
Media temperature [°F] [Max] 194 °F
Media temperature [°F] [Min] 36 °F
Number of ways 2/2
Opening time [ms] [Max] 900 ms
Opening time [ms] [Min] 500 ms
Operating pressure [barg] [Max] 140 barg
Operating pressure [barg] [Min] 4 barg
Operating pressure [psig] [Max] 2000 psig
Operating pressure [psig] [Min] 51 psig
Operation Pilot operated
Outlet connection size [in] 1 in
Parts Program name VDHT
Piston diameter Ø [mm] 35 mm
Product group Valve
Product name Solenoid operated valves
Seal Material FKM
Serviceable Yes
Type VDHT 2/2
Type designation VDHT 1 ED NO
Actuator size [mm] 13.5 mm
Body material AISI 304
Closing Time [ms] [Max] 2000 ms
Closing Time [ms] [Min] 1200 ms
Connection standard NPT
Connection type Thread
Flow [gpm] [Max] 40 gal/min
Flow [gpm] [Min] 0 gal/min
Flow [l/min] [Max] 150 L/min
Flow [l/min] [Min] 0 L/min
Function NO
Inlet connection size [in] 1 in
Material type Neutral media
Media temperature [°C] [Max] 90 °C
Media temperature [°C] [Min] 2 °C
Media temperature [°F] [Max] 194 °F
Media temperature [°F] [Min] 36 °F
Number of ways 2/2
Opening time [ms] [Max] 900 ms
Opening time [ms] [Min] 500 ms
Operating pressure [barg] [Max] 140 barg
Operating pressure [barg] [Min] 4 barg
Operating pressure [psig] [Max] 2000 psig
Operating pressure [psig] [Min] 51 psig
Operation Pilot operated
Outlet connection size [in] 1 in
Parts Program name VDHT
Piston diameter Ø [mm] 35 mm
Product group Valve
Product name Solenoid operated valves
Seal Material FKM
Serviceable Yes
Type VDHT 2/2
Type designation VDHT 1 ED NO
Type: VDHT, Connection standard: NPT, Flow [gpm] [Max]: 40.000, Function: NO, Operation: Pilot operated
